Audio

Inputs

Line Input

• Number of Line In：1 (RCA connectors)
• Input Impedance：47KΩ
• Line Input Sensitivity：-20 dB ~ 0 dB ±2 dB
• Line Input Level Indicator：1 (10 levels)
• Stereo Input Mode：DIP switch 1/2 On
• Mono Input Mode：DIP switch 1/2 Off

Outputs

Link Output

• Number of Link Output：1 (RCA connectors)
• Number of Preamp Output：8 (RCA connectors)
• Preamp Output Level：0 dBV
• Output Impedance：100Ω
• Total Harmonic Distortion：< 0.01%
• Frequency Response：20 Hz ~ 20K Hz (±3 dB)

Control

·         Remote Boot：2-pin terminal block (5.08 mm)

Power

• AC Power Source：AC 100V ~ 240V / 60 Hz
• Type of Power Supply Circuit：Switching Mode
• Unswitched Outlet：1 (Max. 300 W)

General

• Dimensions (W x D x H) / mm：480 x 90 x 44
• Weight：1.6 KG

• Dual power supply circuits with wide dynamic range, ultra-high current and ultra-low distortion
• Eight channels of high-quality preamplifiers output independent quality signal
• Eight channels of volume control for precise individual zone level
• 2/8-zone mono under Mono Mode / 4-zone stereo under Stereo Mode for BGM or voice paging
• Expandable system scale with link output and remote boot functions
